Dominika HAAS
Hotah IP68
OUTDOOR SMARTPHONE
for whom shock is a daily life
for whom a job is something more than we think
for whom sport is more than a hobby
Role
ID design | Following the manufacturing process with R&D's & PM's teams in China and France | Packaging Design | Commercial Support
Professional work launched 2018, MobiWire; Clients: Vodafone | Industrial Design
Care
Market analysis and observations led me to the conclusion that there are currently two main user segments for ruggedized products on the market:
-
niche extreme full rugged phone (Crosscall, Kyocera...)
-
mainstream high-end elegant but resistance device (Samsung, Sony...)
Strategy
Create a new segment device that offers a long-lasting with premium design.
This new well-balanced IP68 rugged device is dedicated to the new type of customers which look for a concept which matches with their new expectations
Approach
create a structural, modern form where function & esthetic will play an important role
expose the main function of the product
use solid-resistance technological solutions and materials
give a freedom, joy and satisfaction to the customers
HOTAH
designed to be extreme
Manufacturing process with Chinese team
Collaborating on a daily bases with our Chinese team of engineers, designers and suppliers during 6 months of product developing. This included around 4 pre-mass production samples which we call "P-1/2/3/4", golden samples, dummies for shops, quality reports and aftersales, and full commercial and technical support of the project.
Corning® Gorilla® Glass 3
Elastomer /double injection on middle housing
LCD 5.0"HD IPS One-cell
water & dust proof cap for hybrid SIM and SC card
rubber water protection inside
screws
middle housing/ RAW plastic with #24 EDM marks
place for battery
antenna area
PCBA stack
NFC / camera/ flash area
plastic battery cover with dedicated texture and UV painting for better resistance
camera deco/ aluminium with diamond cuts
CMF documents
are essential before opening moulds for mass production and for communication with Chinese Suppliers & Design team, in my case based in MobiWire Paris and Fenghua (Ningbo) Factory.
Colours, Materials, Finishes
for the best quality, we have chosen solid materials like hard plastics, TPU and metals. The textures and details where designed to give a comfortable and robust feel and look.
KHAKI GREEN
discrete for B2B business public
HOT RED
for active and sportive public
Black 6C
metallic-satin to add elegance
P-samples follow up
with product managers based in France and China. Usually ppt, or excel documents with indicated parts which need to be updated for the next samples.
Quality tests
each product needs to pass a series of different tests before going on the market. For ruggedized objects, there are additional IP tests as waterproof, fire resistance, drop and dust proof etc. which are made in our factory.
What IP68 stand on?
IP68 stand on Water-proof resistance
> 30 min under 1.5m
IP68
audio jack
IP68
micro USB
type - C
Special IP Micro USB TYPE -C and IP Audio Jack, allows for quick and easy access with water resistance. Additional to pass more than 30min underwater Hotah receiver and speaker are supported with waterproof mesh.
The IP Code, International Protection Marking, IEC standard 60529, sometimes interpreted as Ingress Protection Marking, classifies and rates the degree of protection provided against intrusion (body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures.
for whom sport is more than a hobby
DEDICATED CAMERA BUTTON
GLOVE-TOUCH
Shock-proof & Dust-proof
security for whom job is something more than we think
The comfort of use was extremely important, that's why the shape and texture of the battery cover was design to protect the device from scratches and gives ruggedized look and feel.
Additionally, we dedicated NFC zone for secure and fast payments where ever we are.
discrete lanyard hole for better security
the secure cap for SIM and SD card
double injection of TPU around the device for better shock protection with dedicated texture.
Marketing around the product
To make a story of Hotah more complete, I created a special edition of the packaging to bring users closer to the spirit and purpose of the device.
TEAM WORK
Behind industrial realization is always a large team of dedicated designers, engineers, managers and sales. Special thanks to Alain P. (PM France) for great and endless support and Lixinxin (CMF designer China) thanks to whom a supplier communication was smooth and fruitful.
